Request For Our Latest Prices On Duplex Steel Fasteners in Bangkok, Thailand!
Pengkumta Fasteners provides Duplex Steel Fasteners, with the best features of austenitic and ferritic steel to provide strength and corrosion protection. Our Duplex Steel Fasteners are meant for demanding applications in severe environments, such as marine, chemical, and petrochemical industries. Due to high resistance to pitting, crevice corrosion, and stress corrosion cracking, these fasteners provide long service life and durability. Pengkumta’s Duplex Steel Fasteners are the best option where industries require superior performance under pressure and harsh environments where conventional steel can fail, thus becoming necessary for high-strength use in harsh conditions.
Duplex Steel Fasteners are manufactured using an equi-proportional mixture of austenitic and ferritic stainless steel, having around 22-25% chromium and 4-6% nickel. This material gives excellent mechanical properties, such as high tensile strength (up to 800 MPa) and greater resistance to corrosion, especially in chloride conditions. Duplex Steel has better yield strength compared to other traditional stainless steels, with better impact toughness as well as resistance to stress corrosion cracking. The fasteners have very high fatigue strength and are therefore best suited for applications in tough industrial sectors like oil and gas and chemical processing.
| Phosphorus | Sulphur | Silicon | Carbon | Manganese | Nickel | Molybdenum | Nitrogen | Copper | Chromium |
|---|---|---|---|---|---|---|---|---|---|
| 0.035 % max | 0.02 % max | 0.80 % max | 0.03% Max | 1.20 % max | 6.00 – 8.00 % | 3.00 – 5.00 % | 0.24 – 0.32 % | 0.50 % max | 24.0 – 26.0 % |
| Grade | YS (MPa) | UTS (MPa) | % Elongation | Hardness(BHN) |
| UNS S32750 | 550 min. | 795 min. | 15 min. | 310 max. |
| UNS S32760 | 550 min. | 750 min. | 25 min. | 270 max. |
| Specifications | : | ASTM A182 / ASME SA182 |
| Size | : | 1/8″ NB TO 24″ NB |
| Standards | : | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Class / Pressure | : | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standard | : | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Grades | : | S31803 / S32205 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F6 |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Duplex Steel fasteners are widely used in applications requiring high strength and corrosion resistance. Ideal for marine applications, offshore platforms, chemical plants, oil and gas systems due to durability in harsh environments These fasteners protect critical components in high pressure and high temperature environments, including pipelines, reactors and structural framework ensuring, and reducing maintenance costs
Duplex Steel Fasteners are best used in industries where high strength, toughness, and corrosion resistance are of utmost importance. They find extensive application in oil and gas, chemical, petrochemical, and marine sectors, where they fasten critical equipment that is subject to harsh conditions. They are typically deployed in offshore platforms, heat exchangers, desalination units, and chemical reactors. They are the first choice for fastening high-pressure pipelines, valves, and structural parts due to their resistance to chloride stress corrosion cracking and pitting, thereby providing secure, reliable connections in severe environments. Pengkumta’s Duplex Steel Fasteners assure performance even under harsh conditions.
Pengkumta Fasteners is a leading manufacturer and supplier of high-quality fasteners in Bangkok, Thailand, with over 8 years of experience serving global industries.
