Request For Our Latest Prices On Inconel 617 Stud Bolts in Bangkok, Thailand!
Pengkumta Fasteners, located in Bangkok, Thailand, stands out as a top manufacturer and supplier of high-quality Inconel 617 Stud Bolts. These bolts are crafted for exceptional strength, durability, and corrosion resistance, making them perfect for even the toughest environments. Adhering to international quality standards, they excel in high-temperature and high-pressure situations where reliability is a must. With a focus on precision engineering, thorough quality checks, and timely delivery, Pengkumta Fasteners is your go-to for dependable fastening solutions. Inconel 617 Stud Bolts find their place in various industries, including aerospace, chemical processing, power generation, and marine, ensuring they deliver long-lasting performance, mechanical stability, and resistance to oxidation and harsh chemicals.
The composition of Inconel 617 Stud Bolts includes nickel (44–62%), chromium (20–24%), cobalt (10–15%), and molybdenum (8–10%), along with trace amounts of aluminum and titanium. This well-balanced mix provides impressive tensile strength of about 850–1,000 MPa and high yield strength, along with remarkable creep resistance at elevated temperatures reaching up to 1,000°C. They also maintain their shape, toughness, and resistance to oxidation, carburization, and sulfidation in challenging environments. These mechanical properties make Inconel 617 Stud Bolts a reliable choice for critical fastening in extreme thermal and corrosive conditions.
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Standard ASTM B168, B166 / ASME SB168, SB166
Dimensions ANSI B18.2.1, DIN 931,DIN 933, ISO 4014, ISO 4017,BS 1768, BS1768, IFI 115
Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads
Type Cold Forged, Hot Forged, Bar Stock Machined, Bar Stock Milling
Size M02 to M160
Length 3 mm to 200 mm
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Inconel 617 Stud Bolts are commonly used in gas turbines, heat exchangers, and combustion systems, thanks to their ability to endure extreme heat and pressure. In the chemical and petrochemical sectors, they are essential in reactors, piping systems, and equipment that come into contact with corrosive substances. Power plants utilize them in high-temperature applications, such as superheaters and reheaters. The marine and offshore industries also depend on their resistance to seawater and oxidation. With their unique blend of mechanical strength, corrosion resistance, and thermal stability, Inconel 617 Stud Bolts are vital for industries that require secure and long-lasting fastening solutions.
Our products such as SS 304 Fasteners are packed in a manner that they are not affected by any harm in the course of the delivery. For exports, normal export packing is done in wooden boxes or cases, and all the packing is done according to the international standard packing. All fasteners are marked with Trademark (Company’s LOGO), Grade, Size and Lot No. On customers’ request, we can offer customized marking on the products. Manufacturer Test Certificate as per EN 10204-3. 1, EN 10204-3. 2, Raw Materials Certificate, NABL approved Lab Test Report, 100% Radiography Test Report, Third Party Inspection Report etc.
Pengkumta Fasteners is a leading manufacturer and supplier of high-quality fasteners in Bangkok, Thailand, with over 8 years of experience serving global industries.
